Tipo
Arrastrero al Fresco
Año Construcción
1989 Construcciones Navales Santodomingo SA, España
Clase
DNV, ? 1A1 Stern trawler, Ice(1B)
Tonelaje
1110 GT / 350 NT
Dimensiones
47.60 x 11.90 m
Acomodación
32 tripulantes
Capacidad de Bodega
500 m3
Motor Principal
Wartsila Vasa 2990 CV
Propulsor
Hélice paso variable Wichmann 90PR4 1020, 4 palas en tobera Kort a 120/145 rpm. Diam. 3400 mm
Parque de Pesca
Wet fish factory with 4 chill tanks and no processing machines
Maquinaria de Cubierta
Ulstein Brattvaag maker ■ 2 x 29 ts Split trawl winches DM 3600 ■ 1 x 42 ts Brattvaag trawl winch, new 2002 for third trawl wire, ■ 4 x 10 ts Sweep line winches DSM4185 ■ 2 x 15 ts Gilson winches DM6300
Comentarios
March 2024 - The hull was blasted to 70% SA2½ with 2 coats primer and a full coat Antifouling. The top side and superstructure was mechanically prepped and painted. ■ Main engine was completely overhauled August 2023 including the flywheel and in March 2024 the Vibration damper, Turbo and complete fuel system had a complete overhaul including all ancillary pumps, compressors and receivers. ■ The gearbox was completely overhauled in March 2021 and inspected in March 2024 with positive report. ■ ■ March 2021- Tail shaft was drawn for full Class renewal and replaced with new seals, liners, propeller blades & Nozzle was fitted. In 2024 external inspection and operation inspection done as per DNV requirements. ■ ■ Auxiliary engines Baudouin 6M26.3 - 501KWM 1800 New, installed December 2022 and serviced March 2024 ■ Harbour set - Cummins 6CTA8.3-G2 with NKT220-4 450/220V 1800RPM 225KW 60Hz ■ ■
